- Viewing Head: Compensation free Trino head, Inclined 45° (50mm-75mm)
- Eyepiece: WF10x/22mm, anti-fungal and anti-reflection treated
- Objective: Long working distance plan
- Achromatic objectives: 4x,10x (phase contrast), 20x (phase contrast), 40x(s)
- Stage: Double layer mechanical I Size: 242mm x 172mm
- Central stage: Φ110mm I Moving Range: 75mm x 40mm
- Filter: N.A.0.3 Abbe Condenser with iris diaphragm
- Working Distance:75mm
- Focusing: Coaxial coarse and fine with tension adjustment
- Fine focusing scale value: 0.002mm
- Transmission Illumination: Halogen Bulb 12V/30W adjustable brightness
- Light Source: Epi-Fluorescent Illumination 220V(110V)
- Ultra-high pressure Mercury Lamp 100W/DC
- Digital display mercury lamp constant power
- Fluorescence attachment Blue and Green Wave band
- Optional Accessory:
- 1.3Mega, 2.0 Mega, 3,0 Mega, 5,0 Mega, pixels
- CMOS Digital camera eyepiece, HDMI 1080, HDMI 720p cameras
- Objective: 40x phase contrast U, V Wave band
- Photography attachment and CCD Adapter 0.5x, 0.57x, 0.75x
|
